• ON - Connection Successful
• Flash - Data Receiving and Sending
Flash slowly/
Flash quickly
(Available for C
model)
• Flash slowly 1 (200ms Bright/1800ms Dark)-
Unregistered network (Network searching)
• Flash slowly 2 (200ms Dark/1800ms Bright)- Idle
status (online)
• Flash quickly - Data Transmitting and Receiving
6 Installation
Step 1: Fix the device bracket on the bottom of the enclosure with four M6*12 screws following the direction
shown in the figure below.
Step 2: Tighten the pole clamp bar with bolts, washer, and nuts.
Notes: The diameter of a pole that brackets support is 50-100mm. If the pole diameter is more than this value,
the steel strips can be used. Standard delivery without steel strip and the user should purchase separately.
