9 Accessing the gateway
WI-FI AP MODE
By default, the Gateway will work in Wi-Fi AP Mode which means that you can find an SSID
named "RAK7289_XXXX" on your PC's Wi-Fi Network List. "XXXX" is the last two bytes of the Gateway MAC
address. To access the Web Management Platform, input the IP Address: 192.168.230.1 in your Web browser.
📝 NOTE
No password is required to connect via Wi-Fi
Using your preferred Web browser, input the aforementioned IP Address and you should see the same Log-in Page
shown in the following image. Login with the credentials provided below:
Username: root
Password: root
For WisGate Edge Pro models V2 and H you need to set the login password at the first login.
WAN PORT (ETHERNET)
Connect the Ethernet cable to the port marked “ETH” on the Gateway and the other end to the PoE port of the PoE
injector. Connect the LAN port of the PoE injector to your PC.
The default IP is 169.254.X.X. The last two segments(X.X) are mapped from the last four bits of the MAC address of
your gateway. For example, the last four bits of the MAC address are 0F:01, and the IP address is 169.254.15.1. Make
sure to manually set the address of your PC to one in the same network (for example 169.254.15.100). Use the same
credentials for the Web UI as for AP mode.
Detailed Quick Start Guides for the devices are available in the RAKwireless Documentation Center:
https://docs.rakwireless.com/Product-Categories/WisGate/RAK7289/Overview
10. Certification
CE
Operating frequency range:
Maximum RF output
power（dBm）
863-865, 865-868, 868-868.6,
868.7-869.2, 869.7-870
