To gain access to the “COMMUNICATION” menu from the default display, press 2
once and 6 3 times. The HMI is described below :
COMMUNICATION
Heading of the “COMMUNICATIONS” menu
COMMUNICATION ?
YES
Description : selection of the function "COMMUNICATION"
Range : YES/NO
BAUD RATE
19200 Bd
Description : selection of the baud rate
Range : 300/600/1200/2400/4800/9600/19200/38400
Bauds
Note : message only seen if the communication has been
enabled
PARITY
NONE
Description : selection of the parity
Range : NONE / EVEN / ODD
Note : message only seen if the communication has been
enabled
STOP BITS
1
Description : selection of the stop bits number
Range : 1 or 2
Note : message only seen if the communication has been
enabled
RELAY ADDRESS
1
Description : selection of the Modbus address of the relay
Range : 1 to 255.
Note : message only seen if the communication has been
enabled
9.3.3 Additional menu for P922 and P923
DATE FORMAT =
PRIVATE
Description : selection of the mode of the format of date for
synchronization
Range : PRIVATE or IEC
