P92x/EN FT/E11 Technical Guide
User Guide
Page 82/110 MiCOM P921-P922-P923
11.9.2 MiCOM P921 and MiCOM P922 : common information
To gain access to the “INPUTS” sub-menu from the default display, press once 2, 5
times 6 (P921) or 6 times (P922 or P923), once 2 and 8 times 6.
INPUTS
Heading of the “INPUTS” sub-menu
INPUT 1 =
NONE
Description : allocation of the logic input n°1 to one of the
above listed information.
Range : see the above list of information
INPUT 2 =
NONE
Description : allocation of the logic input n°2 to one of the
above listed information.
Range : see the above list of information
t AUX 1 =
0.0 s
Description : setting of the auxiliary timer associated to the
AUX1 logic input.
Range : 0 – 200s, step = 0,01s
t AUX 2 =
0.0 s
Description : setting of the auxiliary timer associated to the AUX
2 logie input.
Range : 0 – 200s, pas = 0,01s
11.9.3 Additional logic inputs for the MiCOM P922 and P923 relays
INPUT 3 =
NONE
Description : allocation of the logic input n°3 to one of the
above listed information.
Range : see the above list of information
INPUT 4 =
NONE
Description : allocation of the logic input n°4 to one of the
above listed information.
Range : see the above list of information
INPUT 5 =
NONE
Description : allocation of the logic input n°5 to one of the
above listed information.
Range : see the above list of information
