DEFAULT DISPLAY
PASSWORD =
****
DESCRIPTION =
P921--
REFERENCE =
ALST
SOFTWARE VERSION
4.C
FREQUENCY =
50 Hz
INPUTS : 21
00
OP PARAMETERS
OUTPUTS : 4321
0000
GENERAL
CONNECTION
3 Vpn
PROTECTION
PROT P-P
DEFAULT DISPLAY
RMS VA
CONFIGURATION
VT RATIO
MAIN VT PRIMARY =
20.00 kV
MAIN VT SEC’Y =
100 V
LED 5 / 6 / 7 / 8
LED CONF. V< = Y/N tV< = Y/N V<< = Y/N tV<< = Y/N V<<< = Y/N tV<<< = Y/N V> = Y/N tV> = Y/N V>> = Y/N tV>> = Y/N V>>> = Y/N tV>>> = Y/N V0> = Y/N tV0> = Y/N V0>> = Y/N tV0>> = Y/N V0>>> = Y/N tV0>>> = Y/N tAUX1 = Y/N tAUX2 = Y/N
MiCOM P921
Menus
E/Gnd VT PRIMARY=
20.00 kV
E/Gnd VT SEC’Y =
100 V
ALARMS
INST.SELF-RESET ?
YES
INPUTS: 21 11
VOLTAGE INPUTS= DC CONFIGURATION INPUTS
