Areva MiCOM P921 - Page 177

Technical Guide P92x/EN FT/E11
User Guide
MiCOM P921-P922-P923 Page 99/110
DEFAULT DISPLAY
PASSWORD =
****
DESCRIPTION =
P922--
REFERENCE =
ALST
SOFTWARE VERSION
4.C
FREQUENCY =
50 Hz
INPUTS : 54321
00000
OP PARAMETERS
OUTPUTS :87654321
00000000
DATE
12/09/01
TIME
10:33:10
GENERAL
CONNECTION
3 Vpn
PROTECTION
PROT P-P
DEFAULT DISPLAY
RMS VA
CONFIGURATION
VT RATIO
MAIN VT PRIMARY =
20.00 kV
MAIN VT SEC’Y =
100 V
LED 5 / 6 / 7 / 8
LED CONF. V< = Y/N tV< = Y/N V<< = Y/N tV<< = Y/N V<<< = Y/N tV<<< = Y/N V> = Y/N tV> = Y/N V>> = Y/N tV>> = Y/N V>>> = Y/N tV>>> = Y/N V0> = Y/N tV0> = Y/N V0>> = Y/N tV0>> = Y/N V0>>> = Y/N tV0>>> = Y/N tAUX1 = Y/N tAUX2 = Y/N V2> = Y/N tV2> = Y/N V2>> = Y/N tV2>> = Y/N V1< = Y/N tV1< = Y/N V1<<= Y/N tV1<< = Y/N F1/F2/F3/F4/ F5/F6 = Y/N tF1/tF2/tF3 tF4/tF5/tF6 =Y/N f.OUT OF R =Y/N
CONFIG SELECT CHANGE GROUP INPUT EDGE
MiCOM P922
Menus
E/Gnd VT PRIMARY=
20.00 kV
E/Gnd VT SEC’Y =
100 V
ACTIVE GROUP =
1
SETTING GROUP =
1
ALARMS
INST.SELF-RESET ?
YES
ALARMS BATTERY=
NO
