P92x/EN CT/E11 Technical Guide
Modbus Protocol
Page 40/118 MiCOM P921-P922-P923
1.7.14 Page 37h : 5 last fault records data (MiCOM P922 and P923 only)
Read access only.
Address Contents Format
3700h Fault record values n°1 F64
3701h Fault record values n°2 F64
3702h Fault record values n°3 F64
3703h Fault record values n°4 F64
3704h Fault record values n°5 F64
1.7.15 Pages 38h to 3Ch : Selection of the disturbance record and channel (MiCOM P922
and P923 only)
Read access only.
Address
Disturbance record
number
Channel Format
3800h 1 VA F65
3801h 1 VB F65
3802h 1 VC F65
3803h 1 V0 F65
3804h 1 Frequency F65
3805h 1 Logic input and outputs F65
3900h 2 VA F65
3901h 2 VB F65
3902h 2 VC F65
3903h 2 V0 F65
3904h 2 Frequency F65
3905h 2 Logic input and outputs F65
3A00h 3 VA F65
3A01h 3 VB F65
3A02h 3 VC F65
3A03h 3 V0 F65
3A04h 3 Frequency F65
3A05h 3 Logic input and outputs F65
3B00h 4 VA F65
3B01h 4 VB F65
3B02h 4 VC F65
3B03h 4 V0 F65
3B04h 4 Frequency F65
3B05h 4 Logic input and outputs F65
