Modbus Protocol
MiCOM P921-P922-P923 Page 47/118
PRODUCTS
CODE DESCRIPTION
P921 P922 P923
F13 bit 7 : logic output number RL7 X X
bit 8 : logic output number RL8 X X
bits 9 to 15 : reserved
Unsigned integer : logic outputs configuration (excepted
RL1)
bit 0 : selection logic output number RL2 X X X
bit 1 : selection logic output number RL3 X X X
bit 2 : selection logic output number RL4 X X X
bit 3 : selection logic output number RL5 X X
bit 4 : selection logic output number RL6 X X
bit 5 : selection logic output number RL7 X X
F14
bit 6 : selection logic output number RL8 X X
Unsigned integer : Logical input allocation
bit 0 : delatch (UNLATCH)
XXX
bit 1 : 52a
XXX
bit 2 : 52b
XXX
bit 3 : external CB failure (CB fail)
XXX
bit 4 : external input 1 (AUX1)
XXX
bit 5 : external input 2 (AUX2)
XXX
bit 6 : blocking logic 1 (BLK LG1)
XXX
bit 7 : blocking logic 2 (BLK LG2)
XXX
bit 8 : change of active setting group (CHANG SET)
XX
F15
bit 9 : external start of the disturbance recorder (DIST
TRIG)
XX
Unsigned integer : Information generated by the
zero sequence overvoltage function
XXX
bit 0 : instantaneous information (V0>) or (V0>>)
or (V0>>>)
bit 1 to 4 : reserved
bit 5 : instantaneous information (V0>) or (V0>>)
or (V0>>>)
bit 6 : time delayed information (tV0>) or (tV0>>)
or (tV0>>>)
F16
bits 7 to 15 : reserved
