Areva MiCOM P921 - Page 242

P92x/EN CT/E11 Technical Guide
Modbus Protocol
Page 52/118 MiCOM P921-P922-P923
PRODUCTS
CODE DESCRIPTION
P921 P922 P923
F34 Unsigned integer : Latch of auxiliary output relays
bit 0 : selection of the auxiliary output relay no 2
bit 1 : selection of the auxiliary output relay no 3
bit 2 : selection of the auxiliary output relay no 4
bit 3 : selection of the auxiliary output relay no 5
bit 4 : selection of the auxiliary output relay no 6
bit 5 : selection of the auxiliary output relay no 7
bit 6 : selection of the auxiliary output relay no 8
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
Unsigned integer : Disturbance recorder status X X
0 : No record in progress
F35
1 : Record in progress
Unsigned integer : Alarm status (1)
Bit 0 : V0 > XXX
Bit 1 : tV0 > X X X
Bit 2 : V0 >> XXX
Bit 3 : tV0 >> X X X
Bit 4 : V0 >>> XXX
Bit 5 : tV0 >>> X X X
Bit 6 : V2 > X X
Bit 7 : tV2 > X X
Bit 8 : V2 >> X X
Bit 9 : tV2 >> X X
Bit 10 : V1 < X X
Bit 11 : t V1 < X X
Bit 12 : V1 << X X
F36
Bit 13 : tV1 << X X
Unsigned integer : Alarm status (2) X X
Bit 0 : instantaneous information f1
Bit 1 : time delayed information f1
Bit 2 : instantaneous information f2
Bit 3 : time delayed information f2
Bit 4 : instantaneous information f3
Bit 5 : time delayed information f3
Bit 6 : instantaneous information f4
F37
Bit 7 : time delayed information f4
