P92x/EN CT/E11 Technical Guide
Courier Database
Page 72/118 MiCOM P921-P922-P923
Code Event text Description
Associated
COURIER cell
0035 TRIP t V> Trip t V> -
0036 TRIP t V>> Trip t V>> -
0037 TRIP t V>>> Trip t V>>> -
0038 TRIP t V< Trip t V< -
0039 TRIP t V<< Trip t V<< -
0040 TRIP t V<<< Trip t V<<< -
0041 TRIP t V0> Trip t V0> -
0042 TRIP t V0>> Trip t V0>> -
0043 TRIP t V0>>> Trip t V0>>> -
0044 TRIP t Aux1 Trip t Auxiliary 1 -
0045 TRIP t Aux2 Trip t Auxiliary 2 -
0046 TRIP EQUATION A Trip Logical equation A -
0047 TRIP EQUATION B Trip Logical equation B -
0048 Aux Relays Auxiliary relays command 0021
0049 ACK 1 AL (FAV) First alarm acknowledge (Front Panel) -
0050 ACK ALAR (FAV) All alarms acknowledge (Front Panel) -
0051 ACK 1 AL (COM) First alarm acknowledge
(Communication)
-
0052 ACK ALAR (COM) All alarms acknowledge (Communication) -
0053 Hard Maj Alarm Hardware major alarm 0022
0054 Hard Min Alarm Hardware minor alarm 0022
0055 V2 > Start V2> 0024
0056 V2 >> Start V2>> 0024
0057 V1 < Start V1< 0024
0058 V1 << Start V1<< 0024
0059 F1 Start F1 0024
0060 F2 Start F2 0024
0061 F3 Start F3 0024
0062 F4 Start F4 0025
0063 F5 Start F5 0025
0064 F6 Start F6 0025
0065 t V2> Trip V2> 0025
0066 t V2>> Trip V2>> 0025
0067 t V1< Trip V1< 0025
0068 t V1<< Trip V1<< 0025
0069 t F1 Trip F1 0024
