Technical Guide P92x/EN CT/E11 Courier Database MiCOM P921-P922-P923 Page 99/118
Col Row Menu Text Data Type Ind
Values (* : default)
Depend Cell Type Min/Max/Step
62 00 LOGICAL EQUATIONS CONFIGURATION
01 U< Binary (2 bits / 4 bits) 00 * / 0000 * Setting 0 / 3 / 1 or 0 / 15 / 1 02 t U< Binary (2 bits / 4 bits) 00 * / 0000 * Setting 0 / 3 / 1 or 0 / 15 / 1 03 U<< Binary (2 bits / 4 bits) 00 * / 0000 * Setting 0 / 3 / 1 or 0 / 15 / 1 04 t U<< Binary (2 bits / 4 bits) 00 * / 0000 * Setting 0 / 3 / 1 or 0 / 15 / 1 05 U<<< Binary (2 bits / 4 bits) 00 * / 0000 * Setting 0 / 3 / 1 or 0 / 15 / 1 06 t U<<< Binary (2 bits / 4 bits) 00 * / 0000 * Setting 0 / 3 / 1 or 0 / 15 / 1 07 U> Binary (2 bits / 4 bits) 00 * / 0000 * Setting 0 / 3 / 1 or 0 / 15 / 1 08 t U> Binary (2 bits / 4 bits) 00 * / 0000 * Setting 0 / 3 / 1 or 0 / 15 / 1 09 U>> Binary (2 bits / 4 bits) 00 * / 0000 * Setting 0 / 3 / 1 or 0 / 15 / 1 0A t U>> Binary (2 bits / 4 bits) 00 * / 0000 * Setting 0 / 3 / 1 or 0 / 15 / 1 0B U>>> Binary (2 bits / 4 bits) 00 * / 0000 * Setting 0 / 3 / 1 or 0 / 15 / 1 0C t U>>> Binary (2 bits / 4 bits) 00 * / 0000 * Setting 0 / 3 / 1 or 0 / 15 / 1 0D V0> Binary (2 bits / 4 bits) 00 * / 0000 * Setting 0 / 3 / 1 or 0 / 15 / 1 0E t V0> Binary (2 bits / 4 bits) 00 * / 0000 * Setting 0 / 3 / 1 or 0 / 15 / 1 0F V0>> Binary (2 bits / 4 bits) 00 * / 0000 * Setting 0 / 3 / 1 or 0 / 15 / 1 10 t V0>> Binary (2 bits / 4 bits) 00 * / 0000 * Setting 0 / 3 / 1 or 0 / 15 / 1 11 V0>>> Binary (2 bits / 4 bits) 00 * / 0000 * Setting 0 / 3 / 1 or 0 / 15 / 1 12 t V0>>> Binary (2 bits / 4 bits) 00 * / 0000 * Setting 0 / 3 / 1 or 0 / 15 / 1 13 V2> Binary (2 bits / 4 bits) 00 * / 0000 * Setting 0 / 3 / 1 or 0 / 15 / 1 14 t V2> Binary (2 bits / 4 bits) 00 * / 0000 * Setting 0 / 3 / 1 or 0 / 15 / 1 15 V2>> Binary (2 bits / 4 bits) 00 * / 0000 * Setting 0 / 3 / 1 or 0 / 15 / 1 16 t V2>> Binary (2 bits / 4 bits) 00 * / 0000 * Setting 0 / 3 / 1 or 0 / 15 / 1 17 V1< Binary (2 bits / 4 bits) 00 * / 0000 * Setting 0 / 3 / 1 or 0 / 15 / 1 18 t V1< Binary (2 bits / 4 bits) 00 * / 0000 * Setting 0 / 3 / 1 or 0 / 15 / 1 19 V1<< Binary (2 bits / 4 bits) 00 * / 0000 * Setting 0 / 3 / 1 or 0 / 15 / 1 1A t V1<< Binary (2 bits / 4 bits) 00 * / 0000 * Setting 0 / 3 / 1 or 0 / 15 / 1 1B F1 Binary (2 bits / 4 bits) 00 * / 0000 * Setting 0 / 3 / 1 or 0 / 15 / 1 1C t F1 Binary (2 bits / 4 bits) 00 * / 0000 * Setting 0 / 3 / 1 or 0 / 15 / 1
