5. APPENDIX 2
5.1 IEC 60870-5-103 DATABASES
An event is always generated on the rising edge of the information.
Some events can be generated on the rising or lowering edge.
In the list below, events only generated on rising edge will be tagged with a ‘*’.
5.1.1 List of Events produced by the relay
Two types of ASDU can be generated for events : ASDU 1 (time-tagged message) or
ASDU 2 (time-tagged message with relative time).
The list of processed events is following, with the associated INFORMATION
NUMBER, ASDU TYPE and CAUSE OF TRANSMISSION.
Status indications (monitor direction) :
- Leds reset : INF <19>; TYP <1>; COT<1>,*
- Local parameter Setting active : INF <22>; TYP <1>; COT<1>
- Setting Group number 1 active : INF <23>; TYP <1>; COT<1>
- Setting Group number 2 active: INF <24>; TYP <1>; COT<1>
- Auxiliary input 1 : INF <27>; TYP <1>; COT<1>
- Auxiliary input 2 : INF <28>; TYP <1>; COT<1>
- Logical input 1 : INF <161>; TYP <1>; COT<1>
- Logical input 2 : INF <162>; TYP <1>; COT<1>
- Logical input 3 : INF <163>; TYP <1>; COT<1>
- Logical input 4 : INF <164>; TYP <1>; COT<1>
- Logical input 5 : INF <165>; TYP <1>; COT<1>
- Logical output 1 : INF <176>; TYP <1>; COT<1>
- Logical output 2 : INF <177>; TYP <1>; COT<1>
- Logical output 3: INF <178>; TYP <1>; COT<1>
- Logical output 4: INF <179>; TYP <1>; COT<1>
- Logical output 5: (WD) INF <180>; TYP <1>; COT<1>
- Logical output 6: INF <181>; TYP <1>; COT<1>
- Logical output 7: INF <182>; TYP <1>; COT<1>
- Logical output 8: INF <183>; TYP <1>; COT<1>
- Logical output 9: INF <184>; TYP <1>; COT<1>
