Areva MiCOM P921 - Page 311

Technical Guide P92x/EN IN/E11
Installation
MiCOM P921-P922-P923 Page 1/10
abcd
CONTENTS
1. RECEIPT OF RELAYS 3
2. HANDLING OF ELECTRONIC EQUIPMENT 3
3. STOCKAGE 4
4. UNPACKING 4
5. RELAY MOUNTING 5
5.1 Rack Mounting 5
5.2 Panel Mounting 7
6. RELAY WIRING 8
6.1 Medium and Heavy Duty Terminal Block Connections 8
6.2 RS485 Port 9
6.3 Earth Connection 9
