Technical Guide P92x/EN RS/E11
Test Report
MiCOM P921-P922-P923 Page 9/22
* Delete as appropriate
5. RELAY SETTINGS INFORMATION
OPERATION
Default values Settings
Password AAAA
Model MiCOM P92-
Part number ALST
Frequency 50 Hz 50 Hz/60 Hz*
DATE AND
TIME
(P922-P923)
Default values Settings
Date 01 Jan 1994
Time 00 :00 :00
CONFIGURATION
Default values Settings
GENERAL
Wiring 3Vpn 3Vpn
3Vpn+Vr
3Vpp+Vr
2Vpp+Vr *
Protection PROT P-N PROT P-P
PROT P-N*
Default display RMS VA V
A
, V
B
, V
C
V
o
V
ab
, V
bc
, V
ca
V
1
(P922-P923)
V
2
(P922-P923)
Frequency* (P922-P923)
VT RATIO
Prim Phase Vnp= 20.00 kV
Sec Phase Vns= 100 V
Prim Earth Vnp= 20.00 kV
Sec Earth Vns= 100 V
CONFIG SELECT
Change group input Edge Edge/Level
Setting group 1 1/2*
FREQ. and df/dt
CONFIG
