Areva MiCOM P921 - Page 92

P92x/EN FT/E11 Technical Guide
User Guide
Page 14/110 MiCOM P921-P922-P923
HEADINGS OF
COLUMN
SUB – MENUS DESCRIPTION See at
PAGE
BLOCKING LOG1 t Allocation of the selected information to
the blocking logic function 1
62
BLOCKING LOG2 t Allocation of the selected information to
the blocking logic function 2
64
AUX OUTPUT RLY Allocation of the selected information to
the auxiliary output contacts (RL2 to RL8)
65
LATCH OUTPUT
RELAYS
Selection of latched output relays 70
AND LOGIC EQUAT Definition of the 4 logic equations 71
T DELAY EQUATION Definition of the associated timers 79
INPUTS Allocation of the selected information to
the logic inputs
81
CB SUPERVISION Settings related to the CB supervision :
- open/close pulse commands,
- maximum authorised time for the
opening/closing of the CB,
- maximum number of operations
83
RECORDS 85
CB MONITORING Records and diagnosis on the CB 85
FAULT RECORD Display of the last 5 faults 86
DISTURB RECORDER Disturbance recorder settings 87
TIME PEAK VALUE Time period for the average and peak
demands
88
FREQ. DISTURB REC Frequency disturbance settings 88
