DESCRIPTION OF THE APPLIANCE
FRONT VIEW
REAR VIEW
Min/max operating limits (internal temperature)
Cooling: 16 °C DB / 35 °C DB
Dehumidification: 16 °C DB / 35 °C DB
Cooling mode room temperature adjustment range: 16 °C DB / 32 °C DB
1) HANDLES
2) AIR OUTLET
3) CONTROL PANEL - BUTTONS FOR
OPERATION WITHOUT REMOTE CONTROL
4) SIGNAL RECEIVER
5) FINS AND AIR FLOW OUTLET
6) FRONT
7) AIR INTAKE
8) CORD WINDING HOOK
9) DRAINAGE HOLE FOR DEHUMIDIFICATION
FUNCTION
10) AIR INTAKE
11) DRAINAGE HOLE FOR COOLING FUNCTION
12) HANDLES
13) AIR OUTLET AND FITTING
14) POWER CORD OUTLET
15) SWIVEL CASTERS
16) REMOTE CONTROL
1
(16)
