DESCRIPTION OF THE APPLIANCE
FRONT VIEW
REAR VIEW
Min/max operating limits (internal temperature)
Cooling: 7°C DB / 35 °C DB
Dehumidification: 17°C DB / 35 °C DB
Cooling mode room temperature adjustment range: 16 °C DB / 31 °C DB
1) UPPER PANEL
2) CONTROL PANEL – BUTTONS FOR
OPERATION WITHOUT REMOTE CONTROL
3) HANDLE
4) FINS AND AIR FLOW OUTLET
5) FRONT STRUCTURE
6) REAR STRUCTURE
7) SWIVEL CASTERS
8) BASE
9) UPPER FILTER
10) DRAINAGE HOLE FOR DEHUMIDIFICATION
FUNCTION
11) CABLE REEL
12) AIR OUTLET AND FITTING
13) LOWER FILTER
14) DRAINAGE HOLE FOR COOLING FUNCTION
9) H
