Argon 18 KRYPTON - Frame Installed Parts; Di2 Specific Components

KRYPTON : Parts
18
No. Name A18 SKU# Qty
# Parts installed on the frame
4a Rear derailleur hanger with screws M4x8mmF - Model C 37830 1
4b Front derailleur hanger
with screws M5x16mmB & M5x16mmF - Model D 36197 1
4c Seat clamp with screw M5x20mmS and washer 38256 1
4d BB cable guide with screw round head Phillips M5*10mm 38257 1
4e Screws for water bottle cage M5*16mmB 38234 4
4f BB cable guide pipe 38258 1
4g Removable CS cable stopper with screws M3x10mmF 36682 3
4h TT plastic cable stopper 38756 4
4i Di2 BB recess cover guide
with screw round head Phillips M5x10mm 38260 1
# Di2 conguration specic parts
5a FD wire grommet 38891 1
5b Downtube Di2 Grommet 38892 1
5c Downtube Di2 Grommet ller 38893 1
# Also included with the frameset - shipped separately
6 No 37 E + 3D w/TH-881-1 80096 1
7 3D headset tool 36165 1
8 Di2 Battery holder 38446 1 set
