KRYPTON : 3. Cable housing installation (continued)
Front and rear derailleur: Pass
the two cables inside the
frame starting at the top tube
until they comes out under the
bottom bracket.
Pass both cables into the cable
guide (4d). Make sure the
5mm screw is set to 1.5 Nm.
For a Di2 conguration, use
the bottom bracket dedicated
cover for electric shifting (4i).
It’s better to install the cables
before installing the bottom
bracket and crank.
