Argos DAVINA - Components - Fixings

4
Ruler - Use this ruler to help correctly identify the hardware
0 5 10 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100
110 115 120 125 130 135 140 145 150 155 160 165 170
105
Please check you have all the fixings listed below
Note: Some of the fixings are pre-fitted to the larger components. Please check carefully before contacting
Argos regarding any missing fixings.
Components-Fixings
Bolt (M8x60MM) X2
Domed Nut (M8) X8
Curved Washer (Ø8) X12
Spring Washer (1/2")X2
Assembled on pedal axle
bolt (14)
Fix Screw (M5X10MM)X2
Assembled on
Computer (40)
Spring Washer
(Ø10)X4
Pedal Axle Bolt
(R/L) 1X/1X
Wave Washer
( Ø26xØ17.8x0.3MM) X4
Assembled on pedal
axle bolt (14)&Connecting
Shaft (31)
Spring Washer
(Ø10)X2
Assembled on Connecting
Shaft (31)
Safety Nut 1/2"(R/L)
1X/1X
Assembled on pedal hing
bolt (14)
Nut (M10) X4
Washer (Ø10)X4
Allen key BoltM
(10X25MM) X2
Assembled on Connecting
Shaft (31)
Washer (Ø10)X2
Assembled on Connecting
Shaft (31)
Connecting ShaftX1
Carriage Bolt
(M8X15MM) X4
Washer (Ø8)X4
Carriage Bolt
(M8x40MM) X4
Bolt (M10x50MM) X4
Hex head bolt
(M8X25MM) X2
Spring Washer (Ø8)X4
D Washer
(Ø28XØ16XT5.0MM)X2
Multi tool X1
Allen key (6MM) X2
Bolt ( M8x70MM) X2
Allen key (8MM)X1
Multi tool X1
