Finished
top edge
Assembly Instructions
9
Step 14
Shaped
edge
Prepare the right
upright
a: Place a runner on
the right upright as
shown. Slide back the
top of runner and use the
2nd hole from the front
to fit the 1st screw .
b: Slide the runner
back the other way and
fit the 2nd screw into
the corresponding hole
in the right upright .
c: Screw a metal dowel
. into the right upright
. .
Insert 2 large locking
nuts into the right
upright .
Turn the right upright
over
d: Gently tap a mini
block into the left
upright , orientated as
shown.
4
H
H
D
4
4
J
J
B
4
a:
b:
c:
d:
Turn the right
upright over
F
4
Finished
front edge
H
J
H
J
H
D
D
B
F
F
4
4
4
4
