Argos Normandy - Page 11

A
Assembly Instructions
10
Step 15
Prepare the top
Screw 8 metal dowels
into the top .
Note: Tighten the metal
dowels up fully against
the panels.
B
B
B
B
B
B
B
B
B
7
Prepare the top
Screw 8 metal dowels
into the top .
Note: Tighten the metal
dowels up fully against
the panels.
B
B
B
B
B
B
B
B
B
7
Prepare the rail
Insert 2 large locking
nuts into the rail .
Tap 2 wooden dowels
into the rail .
Note: Wooden dowels
must not stick out from
the edge by more than
10mm or they may
damage other panels.
D
9
9
D
D
A
10mm
A
A
9
Step 16
Join the rail to the
uprights
Push the left upright
and the right upright
into the rail .
Use a screwdriver to
tighten the 2 large
locking nuts fitted to
the rail .
Step 17
3
4
9
9
D
Rounded
front edge
7
9
3
4
Finished
front edge
Finished
front edge
