Argos Normandy - Stool Assembly

22
Assembly Instructions
14
Step 24
Step 25
Step 26
Prepare the stool
drawer sides
Insert a small locking
nut into the hole
shown on the stool left
drawer side and stool
right drawer side .
Note: Arrow on locking
nut must point towards
hole in edge of panel.
C
21
22
Attach the stool
drawer sides to the
stool drawer front
Push the stool left
drawer side and stool
right drawer side
onto the back of the
stool drawer front .
Turn the small locking
nuts on the stool left
drawer side and stool
right drawer side .
21
22
20
C
21
22
Fit the stool drawer
base
Slide the stool drawer
base down the
grooves in the stool
drawer sides and
and down into the
groove in the stool
drawer front .
25
21 22
20
20
B
B
C
C
20
21
C
21
C
22
21
22
25
