Argos Normandy - Page 16

Assembly Instructions
15
Step 27
Step 28
Step 29
Prepare the left side
Tap a wooden dowel
into the left side.
Note: Wooden dowels
must not stick out from
the edge by more than
10mm or they may
damage other panels.
A
Prepare the stool rails
Insert 4 large locking
nuts into each of the
stool rails .
D
19
x 2
Fit the stool drawer
back
Fit the stool drawer back
. down onto the stool
drawer base .
Make sure that the stool
drawer base fits into
the groove in the stool
drawer back .
Hold the stool drawer
back in position and
tap the knock-in pegs
through the holes in the
stool drawer sides
and .
23
25
25
23
23
E
21
22
Fit the wedgefixes
Turn the drawer
assembly over and slide
2 wedgefixes into the
front and back grooves,
as shown, and tighten up
the screws.
K
K
D
D
D
D
19
E
E
22
25
21
E
E
23
K
K
