Assembly Instructions
6
Step 8
Prepare the left side
Screw 4 metal dowels
into the left side .
Note: Tighten the metal
dowels up fully against
the panels.
Insert 2 large locking
nuts into the left side
. .
Note: The arrow on the
locking nut must point
towards the hole in the
edge of the panel.
Gently tap a mini block
into the left side ,
orientated as shown.
B
1
B
B
D
D
D
F
F
D
1
F
1
1
D
D
B
B
F
F
Finished
front edge
Step 9
Prepare the right side
Screw 4 metal dowels
into the right side .
Insert 2 large locking
nuts into the right
side .
Gently tap a mini block
into the right side ,
orientated as shown.
B
2
D
2
Step 10
Prepare the 2
modesty panels
Insert 4 large locking
nuts into each of the
2 modesty panels .
D
8
F
2
2
D
D
D
D
8
B
B
B
B
x 2
Finished
edge
