Argos Normandy - Dresser Main Body Assembly

Fit the right side
Push the right side
into the 2 modesty
panels .
Use a screwdriver to
tighten the 2 large
locking nuts fitted to
each modesty .
Finished
top edge
Assembly Instructions
7
Step 11
Shaped
edge
Join the 2 modesty
panels to the left side
Push the 2 modesty
panels onto the left
side .
Use a screwdriver to
tighten the 2 large
locking nuts fitted to
each modesty .
Note: Turn the large
locking nuts as far as
they will go - more than
1/2 a turn.
D
D
8
8
1
D
8
2
8
Step 12
8
1
8
B
D
8
Note: Support this modesty
until the left side has been
fitted in the next step.
Important:
The finished edges on
the modesty panels must
be facing each other
8
2
1
