1. OPERATION AND USE
1.1 System Configuration
1
2
3
4
5
6
7
8
1. Rear Bumper 5. Battery Release Button
2. Battery 6. Side Strap
3. USB Data Lead Socket 7. Ambient Temperature Sensor
4. Front Bumper 8. Removable Handle
1
2
3
4
5
6
7
8
9
10
11
1. Date 7 Time
2. Spot Temperature Target 8. Training Bar
3. Power LED 9. Battery Bar
4. Ambient Temperature Value 10. Spot Temperature Value
5. Image Capture Button 11. Zoom Button
6. ON/OFF Button
