Ariens 921 Series User Manual

GB - 14
1. Skid Shoe
2. Clean-Out Tool
3. Remote Discharge Chute Deflector
(013, 017, 018, 020, 022, 023)
4. Manual Discharge Chute Deflector (019)
5. Belt Cover
6. Headlight (013, 017, 018, 020, 022, 023)
7. Auger
8. Auger Gearcase
9. Scraper Blade
10. Discharge Chute
11. Impeller
12. Chute Crank (013, 019, 020, 022, 023)
13. Quick Stick Chute Rotation (017, 018)
Figure 15
OS7420
OS7415
OS7410
3
3
6
6
12
4
13
13
6
1
2
5
8
7
9
10
11
