GB - 19
IMPORTANT: DO NOT force frozen chute
controls. If frozen, take to warm place until
controls are free.
Discharge Chute Crank
(921013, 019, 020, 022, 023)
(Figure 20)
IMPORTANT: If chute does not stay in set
position, adjust as directed in SERVICE AND
ADJUSTMENTS on page 26, or repair before
operation.
Rotate the Chute with Discharge Chute
Crank.
IMPORTANT: DO NOT force frozen chute
controls. If frozen, take to warm place until
controls are free.
Axle Lock Pin (921019)
(Figure 21)
Use the axle lock pin to lock or unlock the
right or left wheel. Lock both wheels to
increase traction; unlock one wheel to allow
for easier turning of the unit.
NOTE: Unit will not drive with both wheels
unlocked.
Remote Wheel Lock
(921013, 020, 022)
Squeeze and release the remote wheel lock
control to lock the left wheel for better traction
when throwing snow or to unlock the left
wheel for easier steering.
NOTE: The wheel lock will not release when
under load. Do not unlock the wheel while
turning. If the wheel lock will not release, turn
the unit slightly left or right to relieve axle load
and release the axle lock.
If remote wheel lock does not lock or unlock
properly, adjust or repair before operation
(see Remote Wheel Lock on page 26).
Heated Handles (921017, 018)
Turn the heated handles
switch to the ON (1)
position to activate. Turn
the switch to the OFF (2)
position to deactivate.
Figure 21
Wheel Unlocked
Wheel Locked
Axle Lock
Pin
OS6000
