EN - 28
2. Check oil level with suitable dipstick
device. Add lubricant if required.
NOTICE: Inspect seal washer for wear or
rubber deterioration and replace as needed.
IMPORTANT: Use only Ariens L3 synthetic
severe duty gear lube (Part Number
00068800). Use of other lubricants will void
unit warranty.
3. Reinstall oil fill plug and seal washer to
80 lbf-in. (9 N•m).
IMPORTANT: DO NOT OVER-TORQUE!
Note that measurements are in pound force
inches (lbf-in) and NOT pound force foot
(lbf-ft).
IMPORTANT: Be sure to install seal washer
with rubber side down (Figure 25).
IMPORTANT: Improper torquing, omission of
seal washer, or incorrect installation of seal
washer will void unit warranty.
Figure 25
1. Auger Gearcase
2. Oil Fill Plug
3. Seal Washer
2
1
3
