33
MOUNTING ARMS
Model 991085, 086, 087
Item Part No. Qty. Description
1 00451659 1 Discharge Baffle, 48” (991085)
00374159 1 Discharge Baffle, 60" (991087)
00440859 1 Discharge Baffle, 52" (991086)
2 06216100 2 Bolt, Round Head Square Neck .31-18 x 1.00 Grade 5
3 06545400 2 Nut, .31-18 Nyloc Flange
4 06545500 2 Nut, .38-16 Nyloc Flange
5 05948700 2 Bolt, Hex .38-16 x 1.00 Grade 5
6 09238900 2 Weldment, Mower Mounting Pin
7 05435900 AR Bearing, .75 x .875 x 1.00
8 02989151 AR Deck Pusher Arm Weldment
9 03251800 2 Assembly, Mower Mount Arm (Contains items 7 and 8)
10 05970600 2 Bolt, Hex .50-13 x 1.75 Grade 5
11 06307300 2 Washer, Locking .50 x .125 Regular
12 07412900 9 Screw, Tapping .38-16 x .50 Hex Washer Head
1
2
5
6
4
11
10
3
3
7
8
9
12
7
6
5
4
11
8
7
12
12
10
To Next Page
