7
SEAT
Model 991085, 086, 087
Item Part No. Qty. Description
1 03829400 1 Assembly, Seat with Armrests
2 06545400 4 Nut, Nyloc Flange 5/16-18
3 05500901 2 Bushing, Flange .515 x .750 x .745 x 1.00
4 02982751 1 Weldment, Seat Plate
5 03255700 1 Weldment, Seat Shaft
6 07000034 2 Bolt, Shoulder EP .38-16 x .30 Hex
7 06534900 1 Nut, .38-16 Nyloc Flange
8 06224100 2 Bolt, Round Head Square Neck .38-16 x 1.25 Grade 5
9 08300021 2 Spring, Seat
10 06444000 2 Washer, Flat-Steel .406 x 1.00 x .188
11 06533500 2 Nut, Coupling .375-16 x 1.75
12 00337700 2 Hub Cap
13 71600500 1 Kit, Seat Arm Rests
PD0300
7
6
2
5
4
1
3
8
10
9
9
10
3
11
11
12
12
13
13
To Next Page
