MAINTENANCE GUIDE
2. ELECTRICAL UNIT
2.1 Control box access
Tools
TIME
4 min
Remove the front panel as above and pivot the electricl box
1
Unhook the two clip and remove the cover
2
3
2.2 Fuse
Tools
TIME
5 min
Open the control box as above
1
Remove the fuse
2
3

Ariston CLAS SYSTEM One Specifications

General

Fuel Type	Natural Gas / LPG
Mounting	Wall-mounted
ErP Heating Efficiency	A
Modulation	1:7
Heating Output	24 kW
Warranty	2 years
