EN / 19
Power supply
BridgeNet® BUS
8 to 24V max; lithium ion battery
Battery 3.7 VDC
500 mAh
Current draw ≤30mA
Operating temperature -0 to 40°C
Storage temperature with battery -10 to 45°C
Storage temperature without battery -20 to 70°C
Humidity 20% RH to 80% RH
Temperature reading precision +/- 0.5°C
Bus wire length and cross-sectional area
NOTE: TO AVOID INTERFERENCE PROBLEMS, USE
A SHIELDED CABLE OR TWISTED PAIR
CABLE.
max. 50 m
ø min. 0.5 mm²
Insulation class III
Protection rating IP 20
Dimensions 103mm x 103mm x 19.1mm
Product card (with BridgeNet bus system only)
Supplier name ARISTON
Supplier identification model CUBE S NET
Temperature control class V
Energy eciency contribution (%) for space heating +3%
With an optional external sensor or internet weather data:
Temperature control class
VI
Energy eciency contribution (%) for space heating +4%
In a system with 3 zones with 2 room sensors:
Temperature control class
VIII
Energy eciency contribution (%) for space heating +5%
Technical specifications
