Ariston FAST R X ONM 14 - Product Descrption; Overall View; Dimensions

12 /
PRODUCT DESCRIPTION ì
Overall view
Vista complessiva
1. Fumestemperaturethermostat
2. Frame
3. ignition/detectionelectrode
4. Gas pipe
5. Overheatthermostat
6. Gas-watervalve
7. Batterybox
8. P.C.B.
9. Gascollector
10. Inletwaterpipe
11. Burner
12. Heatexchanger
13. Combustionhood
13
12
11
9
8
7
6
5
3
1
4
10
2
Overall dimensions
A.  Hotwateroutlet1/2”
B. IngressoGas1/2”
C. Coldwaterinlet1/2”
Model Ø a b c d e f g h i j k l m
weight
gross net
11L 113
617
40,8 102 208 310
58,8 93,3 210,8 255,2 0,6 18,5 92,8
13,6 11,6 10,2
14 L 132 70 132 238 370 10,6 13,0 11,6
b
e
c
a
Ø
d
l
m
f
j
i
g
h
k
A
B
C
A
B
C
