PRODUCT DESCRIPTION
Display
Digits indicating:
- set temperature
- menu settings
- error code signals
Reset button request
Technical assistance request
Flame detected
Heating operation set
Heating operation active
Hot water operation set
Hot water operation active
Anti-frost Function Active
Control Panel
Legend :
1. ON/OFF and operating mode selection button
2. Domestic hot water temperature adjustment buttons +/- (a)
3. Display
4. C. heating temperature adjustment buttons +/- (b)
5. RESET button
(a) Pressing the buttons simultaneously allows for accessing the setting, adjustment
and diagnostics parameters
(b) Pressing the buttons to modify and save the parameter settings
Tableau de commande
1
2
3 4 5
HS C
