6.2.2 Removing the sealed chamber front cover
1. Remove the screws “C” (FIG. 6.5);
2
.
L
ift the sealed chamber front cover from the locating
pins (FIG. 6.6).
FIG. 6.5
C
C
FIG. 6.6
6.2.3 Removing the side panels
1. Remove the four screws “D” for each side panel
(
F
IG.
6.7);
2. Pull the panel away from the boiler at the base, then lift
the panel up and remove from the boiler.
D
D
D
FI
G
. 6.7
D
