2000 SERIES SENSORS INSTALLATION GUIDE Revision 3.1 June 1997
Local supply current (standby)........ <11.0mA @ 24 VDC
Local supply current (alarm) ........... <72.0mA @ 24 VDC plus bell loop load current
Supervisory voltage ........................ approx. 2.2 VDC (inverted)
Bell loop voltage in alarm................ 12 or 24 VDC
Fuse rating...................................... 3A
Physical dimensions ....................... See paragraph 2.5.1, Zone Monitoring Unit
Mounting holes ............................... See paragraph 2.5.1, Zone Monitoring Unit
Operating & storage temperature ... See paragraph 2.2.4
INSTALLATION
Figure 14 : Location of Jumpers and Connectors on the PCB
