Guidance and manufacturer’s declaration: electromagnetic immunity
Immunity test IEC 60601-1-2 test
level
Compliance level Electromagnetic
environment - guidance
Electrostatic discharge
(ESD)
EN 61000-4-2
±2kV, ±4kV, ±8kV,
±15kV air
±8kV contact
±2kV, ±4kV, ±8kV,
±15kV air
±8kV contact
Floors should be wood,
concrete or ceramic tile.
If floors are covered with
synthetic material the
relative humidity level
should be at least 30%.
Conducted
disturbances inducted
by
RF fields
EN 61000-4-6
3V in 0,15 MHz
to 80 MHz
6V in ISM and amateur
radio bands between
0,15 MHz and 80 MHz
80% AM at 1 kHz
3V in 0,15 MHz
to 80 MHz
6V in ISM and amateur
radio bands between
0,15 MHz and 80 MHz
80% AM at 1 kHz
Portable and mobile RF
communications equipment
should be used no closer to
any part of the product,
including cables, than 1.0 m,
if the transmitter’s output
power rating exceeds 1W
a
Field strengths from fixed
RF transmitters, as
determined by an
electromagnetic site survey,
should be less than the
compliance level in each
frequency range
b
Interference may occur in
the vicinity of equipment
marked with this symbol:
Radiated RF
electromagnetic field
EN 61000-4-3
Professional
Healthcare
environment
3 V/m
80 MHz to 2,7 GHz
80% AM at 1 kHz
Professional
Healthcare
environment
3 V/m
80 MHz to 2,7 GHz
80% AM at 1 kHz
Proximity fields from
RF wireless
communications
equipment
EN 61000-4-3
385 MHz - 27 V/m
450 MHz - 28 V/m
710, 745, 780 MHz
- 9V/m
810, 870, 930 MHz
- 28 V/m
1720, 1845, 1970, 2450
MHz- 28 V/m
5240,5500, 5785 MHz -
9V/m
385 MHz - 27 V/m
450 MHz - 28 V/m
710, 745, 780 MHz -
9V/m
810, 870, 930 MHz - 28
V/m
1720, 1845, 1970, 2450
MHz - 28 V/m
5240,5500, 5785 MHz -
9V/m
Electrical fast transient/
burst
EN 61000-4-4
±1kV SIP/SOP ports
100 kHz repetition
frequency
±1kV SIP/SOP ports
100 kHz repetition
frequency
Power frequency
Magnetic field
EN 61000-4-8
30 A/m
50 Hz or 60 Hz
30 A/m
50 Hz
Power frequency magnetic
fields should be at levels
characteristic of a typical
location in a typical
commercial or hospital
environment.
a
Field strengths from fixed transmitters, such as base stations for radio (cellular/cordless) telephones and
land mobile radios, amateur radio, AM and FM radio broadcast and TV broadcast cannot be predicted
theoretically with accuracy. To assess the electromagnetic environment due to fixed RF transmitters, an
electromagnetic site survey should be considered. If the measured field strength in the location in which
the product is used exceeds the applicable RF compliance level above, the product should be observed to
verify normal operation. If abnormal performance is observed, additional measures may be necessary.
b
Over the frequency range 150 kHz to 80 MHz, field strengths should be less than 1 V/m.
