5
Product description
Parts referred to in this manual
1. Mast
2. Chassis
3. Adjustable width chassis legs
4. Rear castors (braked)
5. Lift actuator
6. Jib
7. Manoeuvring handle
8. Battery pack
9. Hand control (for raising and lowering)
10.Electric / Battery compartment
11.Spreader bar
12.Sling attachment hooks
13.Scale unit and display (if fitted)
14.System failure lower override
15.Power off button
16.Power on / Reset button
17.LCD
17A: Battery discharge indicator
17B. Hour/Cycle meter
18.Dual control switch for raising UP
19.Dual control switch for lowering DOWN
20.Front castor
21.Battery release button
22.Emergency stop button
Entire Product
Type B. Applied part:
Protection against electric shock
in accordance with EN 60601-1.
1
2
3
4
5
6
7
8
9
16
19
10
11
12
13
14
15
18
21
17
20
22
Fig. 1
