ARKSCAN ES301 - Product Contents and Introduction; Out of the Box Items; Product Introduction; Specifications

OUT OF THE BOX
Mini Wireless
Barcode Reader
CD
Quick Guide Quick Connection Card
USB Charger Cable Hand Strap
- 3 -
INTRODUCTION
SPECIFICATIONS
LED Indicator
Mini USB port
Exit Window
Trigger
(w/ Protective Cover)
Light source 625nm visible red LED
Scan rate 240 scans/sec
Sensor Linear CMOS sensor
Resolution 5mil/ 0.127mm
PCS 30%
Housing Plastic(PC)
Profile SPP, HID
Battery Life 5400 scans (1 scan/ 5 sec)
Charge Time 2 hours (fully charged)
Coverage 10M/33ft. (line of sight)
Operating Temp 0 to 50˚C (32˚F to 122˚F)
Symbologies All major 1D barcodes incl. GS1 Databar
- 4 -
Mini Wireless
Barcode Reader
Quick Guide
NUMERIC BARCODES
1
*1*
2
*2*
3
*3*
4
*4*
5
*5*
Wireless Scanner Tools
