C
hapter
Ⅳ
P
rogramming on
FAB
panel
The rst line: the day system
The second line: year, month and day
The third line: the output ON time (T1)
The forth line: the output OFF time (T2)
2) If the week system W is selected, the following will be displayed on the
LCD panel:
Fig. 4.11
The type of the week can be selected by pressing 、 keys.
MO: Monday TU: Tuesday
WE: Wednesday TH: Thursday
F
R: Friday SA: Saturday
SU: Sunday
MO-TH: each day from Monday to Thursday
MO-FR: each day from Monday to Friday
MO-SA: each day from Monday to Saturday
MO-SU: each day from Monday to Sunday
FR-SU: each day from Friday to Sunday
SA-SU: each day from Saturday to Sunday
After selecting the week system, press the ESC key and then the timing can se-
lected, which will be b displayed on LCD as follows:
Fig. 4.12
The rst line: the week system
The second line: year/month/day
The third line: the output-ON time
The forth line: the output-OFF time.
Week
00
SU
47
Day
D 2000,00,00
T1 000000
T2 000000
