C
hapter
Ⅳ
P
rogramming on
FAB
panel
5. Set the AN block
AN block is shown as follows:
Input 1: Input I and Input K are available for options.
(1) Input I means this port is connected to FABs input, whose assignment range
is I1~I6 (AF-10 series) and I1~IC (AF-20 series). Its operation on the LCD panel
is the same with that of general I. While K means a digital value, whose range is
between 000 and 100, which represents a voltage ranging from 0V to 10.0V. The
rst two digits represent integer, while the last one represents the decimal part.
(2) When input 1 is K or I, press OK to conrm and then to press
and
to change the digital value. Finally press OK to conrm.
Input 2: It represents function selection. Five comparison functions, >,<,
<,>,=and ≠, are available for choice. Select by using
, and then press
OK to conrm.
Input 3: It is the same with Input 1.
4.3.1.2 Insert FB
This function can be used to insert a function block into a scheduled block posi-
tion. The operating process is as follows:
1. Press OK when the cursor points at “Insert FB” in the Editor Frame, that’s,
“>Insert FB”, then the inserting status appears, as shown in Fig. 4.15.
Fig. 4.15 Insert Function Block
Input 1
Input 2
Input 3
49
Inset
000
