Temperature
Warning
There is a minor sensor-temperature offset.
Image quality may be slightly affected.
Temperature Error
There is a substantial sensor-temperature
offset. Image quality may be seriously affected.
Lock
The Main Controls are locked.
SD Card
An SD card is present. The icon turns orange
when the card is accessed.
Grab
The GRAB icon flashes while a still frame is
being taken and written to the SD card.
High Humidity
Mode
The sensor is in High Humidity mode (i.e. the
sensor is kept at 40° C sensor temperature to
avoid condensation).
Radio
The ARRI Wireless Remote System (WRS) radio
is active.
Note: A sensor temperature warning or error after boot-up is normal as the
sensor takes a few seconds to reach its preset temperature.
11.1.3.1 Lists and User Lists
On the HOME screen, press the FPS, SHUTTER, WB (white balance)
and EI (exposure index) buttons to open lists of preconfigured values
for each setting.
User-defined values can be added to the FPS, SHUTTER and WB lists.
The EI list is fixed and user-defined values cannot be added. It contains
values from 160-3200 ASA in steps of 1/3 stops.
Setting a list value
Figure 42: SENSOR FPS screen
Any value in a list may be set. Invalid values will appear grayed out.
To set a list value:
