ARRI SkyPanel S60 - Page 20

Overview
20
Power Supply Unit S60 / S120 Power Supply Unit S30
Power in and thru
Power out
48 V =
Main switch
Figure 4: Power supply unit S60 / S120
Power out 48 V =
Main switch
Front panel
Power in
and thru
Back panel
Figure 5: Power supply unit S30
