Protocol
53
Protocol
Protocol V4.2 is set as default. Use the ALSM to change to Pro-
tocol V4.1 or V3.4. ARRI recommends to reserve 4 channels
more for each fixture when using Protocol V3.4. This way you
do not need to change the patch when you want to use addi-
tional features which will become available with Protocol V4.2.
The Protocol V4.2 uses 4 Channels more.
SkyPanel-RP
From Firmware-Version 2.5
Mode 1: 8 bit Resolution per Function
Mode 2: 16 bit Resolution per Function
Modus 3: Coarse / Fine per Function
8 bit, 1 channel
per function
16 bit, 2 chan-
nels per function
Coarse/fine, 1-2 chan-
nels per function
Mode 1 Mode 2 Mode 3
Channel Value Percent Function
1
0-255 0-100
Master Intensity
0 % 100% (open)
2
Reverts to
fixture set-
ting when
signal lost.
0-9
10-60
61-120
121-180
181-250
251-255
0-4
5-23
24-47
48-70
71-98
99-100
Fan Control
No function
Low
Variable
High
Fan max. speed
Fan off
3-5 Reserved (only V4.x)
Channel Value Percent Function
1HI
0-65.535 0-100
Master Intensity
0 % 100% (open)
2LO
3
Reverts to
fixture set-
ting when
signal lost.
0-9
10-60
61-120
121-180
181-250
251-255
0-4
5-23
24-47
48-70
71-98
99-100
Fan Control
No function
Low
Variable
High
Fan max. speed
Fan off
4-6 Reserved (only V4.x)
Channel Value Percent Function
1
0-255 0-100
Master Intensity coarse
0 % 100% (open)
2 0-255 0-100 Master Intensity fine
3
Reverts to
fixture set-
ting when
signal lost.
0-9
10-60
61-120
121-180
181-250
251-255
0-4
5-23
24-47
48-70
71-98
99-100
Fan Control
No function
Low
Variable
High
Fan max. speed
Fan off
4-6 Reserved (only V4.x)
