40 Appendix
embedded in SDI signal
Modulation process and other
specifics
OFDM (Orthogonal Frequen-
cy-Division Multiplexing)
Bandwidth 40MHz
NOTICE
Use only ARRI-recommended power supply solutions. WVR-1
accepts an input voltage range from 10.5 to 34 V DC. Do not
supply power outside the specified voltage range as this may
damage the device. The WVR-1 can be powered through the
PWR IN connector or battery adapters accepting V-Lock, Gold
Mount or Sony L-Series batteries.
13.6 Specifications WVR-1s
Power:
Power supply 10.5V to 34V
Power consumption 7W
Power outputs 12V max. 2.0A
Video inputs & outputs:
Output resolutions 1920 x 1080
Frame rates (fps) p: 23.98, 24, 25, 29.97, 30
psF: 23.98, 24, 25, 29.97, 30
Video signal outputs via BNC (1.5 HD-SDI/3G-
SDI)
Video transmission:
Range 150m (5,00ft) line of sight
Latency < 1ms
Encryption 128bit AES
