Arris Touchstone CM8200B - Common home connection with splitter

nbn
™
connection box
Your own or your service
provider’s gateway (router)
Home phone
(via VoiP)
Splitter
Coaxial wall
outlet
POWER
DOWNSTREAM
UPSTREAM
ONLINE
CM8200
Power
outlet
Pay TV
OUT
IN
OUT
Power adaptor Coaxial cable
(white)
Coaxial cable
(not supplied)
Ethernet cable
(not supplied)
2
x
Common home connection
Connecting to the nbn
™
network 4
