Arrow CT50 - DEFINITION OF SYMBOLS USED ON TOOL; Electrical Symbols; Safety Symbols; FUNCTIONAL DESCRIPTION

5
BACK TO
INDEX
V …………………………… Volts
A …………………………… Amperes
Hz……………………………. Hertz
……………………………. Direct Current
……………………………. Alternating Current
……………………………. Alert
……………………………. Wear Eye Protection
……………………………. Wear Ear Protection
DEFINITION OF SYMBOLS USED ON TOOL
FUNCTIONAL DESCRIPTION
1
2
3
4
5
6
7
8
9
Depth of drive dial
Battery Power Meter
10.8V Lithium-Ion Battery
Battery Release
Trigger
Staple Chamber Release
Staple Chamber
Staple Supply
Window
Staple Exit
LED Guide Light
10
1
2
3
4
5
6
7
8
9
10
~
