Parts List
V12
12
Assembly Part Part Quantity Check
Key No. Number Description in Carton List
1 3719 Door Handle Brace 2
2 8200 Wall Panel (Side) 4
3 9374 Front Wall Panel 2
4 9365 Front Wall Channel 2
5 5986 Rear Wall Angle 2
6 6000 Right Gable 2
7 6001 Left Gable 2
8 10497 Horizontal Door Brace 4
9 6300 Vertical Door Brace 2
10 6403 Door Track Splice 1
11 9366 Door Track 2
12 6627 Wall Panel 6
13 6529 Roof Panel 2
14 6635 Gable Brace 2
15 10477 Right Door 1
16 10477 Left Door 1
17 7483 Roof Panel 4
18 9370 Door Jamb 2
19 9917 Rear Wall Channel 2
20 8468 Right Roof Panel 2
21 8469 Left Roof Panel 2
22 8485 Left Side Roof Trim 2
23 8840 Ridge Cap 1
24 10470 Roof Beam 8
25 8836 Right Side Roof Trim 2
26 9922 Side Wall Channel 4
27 8839 Side Wall Angle 4
28 8486 Ridge Cap 1
29 8934 Ramp 1
30 9367 Front Floor Frame 2
31 8936 Rear Floor Frame 2
32 8937 Side Floor Frame 4
33 8471 Corner Panel 4
